The Default Operation Screen is divided into ve (5) sections:

: Located on the left side of the screen, this shows the status

of the fans/heaters, load and unload augers and meter rolls. It will also display the grain

temperature, moisture content, moisture control setpoint and the bushel counter.

Located at the very top of the right side, the dryer status will tell the user if the

dryer is stopped, started, loading or unloading.

This chart, located directly under dryer status, will show the grain

temperature, moisture in/out, temperature out and meter roll output (M.R.O) over a

period of time.

Located directly below the dryer status chart, the plenum section will show

temperature setpoint, actual plenum temperature and burner status.

Select from Timers, Temp, Setup, View and M/C buttons.



Use the following buttons to access these system settings:

Select this button to modify , , 

, , and .

Select this button to modify the and the



Select this button to modify , ,

, , , 

, and the .

Select this button to see the , , ,

,  and .

Select this button to access  and

.

Located within the Setup Screen, selecting this button

allows you to modify , , 

, , , 

, , , ,

 and .

Note: Screen shot of 1100 Series Dryer.

Screens are similar but may vary slightly

depending on model.

QSG-001



Model Number:

Dryer Serial Number:

Number of Modules/Fans/Heaters:

Fuel/Length:

Electrical Phase/Voltage:

ContRolS

5 SPEED

AUTO

HI 575

RPM 9.9

BPH 1610

TB 3439

130 °F

17.0%

- 

- 

-

- 

- 

- 



- 

The GSI Group, LLC • 1004 East Illinois Street • Assumption, IL 62510

QSG-001

notICE: PRIoR to oPERAtIon, READ tHE

oWnERS MAnUAl FoR IMPoRtAnt SAFEtY

InStRUCtIonS AnD FUll EQUIPMEnt DEtAIlS

QSG-001 April/11



NOTE: Default settings work well in most cases.

1. Power on using the Control Power switch and wait 30 seconds.

2. Now viewing the “Boot Screen”, select “Start Dryer”.

3. Setup timers.

4. Using the “Setup” screen, select the following options to congure the dryer.

a.) Select drying mode settings.

b.) Check unload parameter settings

c.) Select moisture control settings.

d.) Check burner mode settings.

5. Using the “Extended Setup Screen”, select the following options to congure the dryer.

a.) Check data logger settings.

b.) Check date and time settings

c.) Check temp scale settings.
